China Standard Thermoplastic Road Marking Paint with Glass Beads Good Reflecitve Fast Drying
Description
Hot melt marking paint is solid powder at room temperature. During construction, the paint is put into the melting kettle, and the temperature in the kettle is controlled between 180 ° C and 210 ° C. While melting, it is stirred, and after melting, it is put into the insulation melting hopper of the marking car. Melt coating then back into the marking bucket, and heat preservation to keep the material molten state. Before the line is marked by the pre-marking machine position, according to the design drawing indicated on the coating position with the lower coating machine primer. The marking coating can be applied only after the coating agent dries thoroughly. When the scribing begins, the scribing bucket should be placed on the road, because there is a certain gap between the scribing bucket and the ground, when the scribing car ahead, by automatic flow and scrape out a neat line. The glass bead spreader can automatically and evenly spread a layer of reflective glass beads on the marking line.
Technical Specification
| Density(g/cm3) | 1.8-2.3 |
| Softening point (℃) | 90-125 |
| Compressive Strength(MPa) | ≥12 |
| Glass bead content(%) | 0-30% |
| Liquidity | 35±10 |
| Packing | 25kg/bag |
| Color | White/Yellow/Blue/Red/Green/Customized |
| Executive standard | JT/T280-2004/AASHTO/BS3262/Customized |
| Appearance | Powder |
| Construction temperature | 180℃-220℃ |
| Whiteness | 70-85(Customized) |
| Inverse coefficient | 50-550 |
| Warranty | 12 months |
| Storage Method | Avoid light and moisture |
| Packing Size | 45×70×5CM |
Main Components and Features
1. Titanium dioxide: Good whiteness, high purity, small particle size, low oil absorption
2. C5 resin: Outstanding affinity for pigments, good compatibility with EVA, good heat stability
3. PE wax: Heat resistance, abrasion resistance, as a lubricant, increase paint processing performance.
4. Calcium carbonate: High precise classification, high whiteness
5. Glass beads: Drop on glass beads, intermix glass bead, we use top brand beads brand, high reflective.
Formula Customized
| Customized Formula |
| Customized Formula | Content(Customized range) | Characteristics |
| C5 Resin | 10%-22% | Fluidity Toughness Hardness Adhesion |
| Titanium Dioxide | 0.5-10% | 0.5%-30% |
| Premixed glass beads | 0%-30% | Reflective after surface wear |
| Calcium Carbonate Sand | 30%-80% | Whiteness Wear-resistant Hardness |
| PE Wax | 1%-1.5% | Cold and heat resistant |
| EVA | 0.5%-1% | Crack resistance |
| Plasticizer | 1%-1.5% | Toughness |
Different Standards
| | AASHTO Standard |
| Components | Specification | Test Result |
| Resin | ≥ 20% | 22% |
| Titanium Dioxide | ≥ 10% | 10.2% |
| Glass Beads | ≥ 30% | 32% |
| | British Standard |
| Components | Specification | Test Result |
| Resin | ≥ 20% | 21% |
| Titanium Dioxide | ≥ 10% | 12% |
| Glass Beads | ≥ 20% | 21% |
| | China Standard |
| Components | Specification | Test Result |
| Resin | ≥ 15% | 16.1% |
| Titanium Dioxide | ≥ 5% | 8% |
| Glass Beads | ≥ 20% | 22% |
