Energy Saving Hydraulic Double Pre-Heater Thermoplastic Paint Preheater kneader
CK800/CK1000/CK1200 pre-heater is one of the mainequipment for thermoplastic marking construction.It is one kind of thermoplastic paint melting equipmentwith the advantages of high efficiency, quality meltingmaterials,less fuel consumption, energy saving, easyoperation and high safety.
Thermoplastic powder paint will be melted into liquid condition after being heated up to 180°c+, then it can be transferred to thermoplastic road marking machine for traffic line markings.
In the process of marking lines ,the first step is to heat and stir the powdery paint in the preheater until it turns into the liquid paint ,then pours the paint into the marking machine for the marking operation . Since the melting level of the paint has a direct bearing on the quality of marking lines ,the preheater plays an important role among the thermoplastic marking devices and is an essential part for melting paint .
| Technical Parameters |
| Type | CK700/CK800/CK1000/CK1200 |
| Engine | 15PS electric start evaporation water cooled diesel engine |
| Hydraulic system | Integrated multiplex hydraulic control valve , forward and reverse stir CVT |
| Hydraulic motor type | BM type |
| Hydraulic tank volume | 40 litres |
| The Kettle | 360x2kg/500x2kg/600x2kg ,Hiigh carbon steel stainless Steel cylinderthe bottom of the pot ,erect paddle mixer |
| Struicture | Multiple heat preservation: normal insulation material, compositeinsulation material, heat transfer oil; |
| Heating system | Multiple heating methods: normal LPG burner or LPG energy efficient burner |
| Safety device | Overload relief device specially designed, can prevent misoperation |
| Size | CK700:1750X1620X1190mm(Special low kettle for underground parking lot ]CK800:1730X1620X1570mmCK1000:1750X1620X1700mm CK1200:1860X1820X1700mm |
| Net weight | 700kg/1000kg/1200kg |
